Rubber and Plastic Insulation Tube
Low Thermal Conductivity and Durable Insulation
The rubber and plastic insulation tube features low thermal conductivity and a fully closed-cell structure, ensuring long-lasting and excellent insulation performance. The material is completely impermeable to water vapor, does not absorb water, resists combustion, prevents condensation, and has a long service life.
At 0°C, the thermal conductivity does not exceed 0.034 W/m·K. Its fire performance boasts an oxygen index of over 32, and its surface heat release coefficient is 9 W/m²·K.
Tested by SGS, the actual measured values are far below the EU standards for non-toxic substances, making it safe and healthy for use. Its soft, attractive appearance, flexibility, and ease of bending make it convenient and efficient to install without requiring additional materials.
---
Excellent Vibration Resistance
Rubber and plastic insulation tubes possess high elasticity, effectively minimizing vibrations and resonance in chilled water and hot water pipes during operation.
---
Flexibility
The insulation tube is highly flexible, making it easy to handle curved and irregular pipes during installation. This reduces labor and material costs.
---
Easy Installation and Aesthetic Appearance
Due to its softness, the product is simple and convenient to install. For pipe installation, the tube can either be directly sleeved onto the pipe or cut longitudinally and rejoined with aluminum foil tape. For complex components such as valves, tees, and elbows, the sheet material can be cut and wrapped to ensure system tightness and insulation.
Its smooth rubber exterior eliminates the need for an additional vapor barrier or protective layer, simplifying installation while maintaining an attractive, flat appearance. Additionally, when equipment or pipes require maintenance, the insulation material can be reused without loss of performance.
---
Additional Advantages
Rubber and plastic insulation tubes are safe to use, do not irritate the skin, and pose no health hazards. They resist mold growth, deter pests, and are resistant to acid and alkali corrosion. These properties make rubber and plastic insulation an ideal material for protecting pipes from atmospheric or industrial environmental corrosion.
---
Fire Resistance
- Flame Retardant: Does not burn easily and self-extinguishes upon removal from the fire source.
- Closed-Cell Structure: The ACMF foaming technology effectively prevents heat conduction.
- Thermal Conductivity: ≤ 0.034 W/m·K at 0°C.
- Surface Heat Release Coefficient: Up to 9 W/m²·K.
---
Moisture Resistance
The material exhibits excellent resistance to water vapor penetration, with a moisture resistance factor (μ) ≥ 5,000, forming a built-in waterproof layer. This means the insulation layer also acts as a moisture barrier.
---
Fire Performance
With an oxygen index exceeding 32, the insulation provides excellent fire resistance.
---
Eco-Friendly and Safe
The product contains no CFCs, HFCs, HCFCs, formaldehyde, dust, or fibers, ensuring an environmentally friendly and safe insulation solution.
---
Wide Operating Temperature Range
The rubber and plastic insulation tube performs well in a temperature range from -50°C to 110°C.
